Eudyna 10Gb/s Optic EML Modulator Integrated DFB Laser Diode Module 1531.90nm FLD5F20CE

Features

• 10Gb/s Modulator Integrated DFB Laser Diode Module

• Wavelength: ITU-T grid W9180 (1563.05nm) thru W9600 (1529.55nm)

• 1600 ps/nm Dispersion

• Compact package with GPO connector

• Built-in Optical Isolator, Ternary PIN-PD for monitor, thermistor and

thermoelectric cooler

• Wavelength locker integrated MI-DFB

Application

This MI DFB laser is intended for long reach applications (80km)

at 10Gb/s.

Description

The Modulator Integrated DFB Laser (MI DFB Laser) with Wavelength Locker has an

electro-absorption modulator monolithically integrated with a conventional Distributed

Feed-Back (DFB) laser. The modulation voltage is applied to the modulator section while the

laser section operates CW allowing extremely low wavelength chirping. Extinction ratios of

more that 10dB can be achieved with 2.6 Vp-p modulation. The MI laser is installed in a butterfly

type package. The tuned wavelength can be locked onto the desired ITU-T grid channel

via use of the included fabry-perot etalon. The module incorporates a highly stable optical

coupling system. The module includes an optical isolator, monitor photodiode, thermistor and

a thermo-electric cooler.
