Finisar 40G速率 菲尼萨高速光电探测器 MPRV1331A 带光纤
带光纤尾纤输入,速率43Gbps, PIN-TIA探测器, 典型灵敏度-10dBm@1550nm, -7dBm@1310nm; 2100V/W转换增益, 输出限幅, 差分摆幅最大可到700mV, 可用于微波光子通信; 差分AC耦合射频信号输出, 双GPPO口;

Finisar 40G速率 菲尼萨高速光电探测器 MPRV1331A 带光纤


带光纤尾纤输入,速率43Gbps, PIN-TIA探测器, 典型灵敏度-10dBm@1550nm, -7dBm@1310nm;

2100V/W转换增益, 输出限幅, 差分摆幅最大可到700mV, 可用于微波光子通信; 差分AC耦合射频信号输出, 双GPPO口;


MPRV1331A

MPRV1332A

PT-40/AC

FU-397SPP



The MPRV1331A is a differential photoreceiver module with very high differential conversion

gain of typ. 2100 V/W and a bandwidth of 31 GHz.

The photoreceiver module MPRV1331A contains a waveguide-integrated PIN-photodiode (PD)

and a transimpedance amplifier (TIA) with limiting output buffer.

An integrated feedback loop optimizes the performance in the frequency and/or time domain with

respect to different optical input power.

Due to the limiting output buffer the differential output voltage swing is limited to 700 mV.

Incorporated blocking capacitors enable AC output coupling. Wavelength support of 1310 and 1550 nm.













>
