EOSPACE 40GB/S Low-loss Wideband Intensity Modulators 1310nm OC-768 Application

40+ GB/S MODULATORS

Low-loss and wideband intensity modulators for OC-768 applications

Package Dimensions: 3.48" x 0.35" x 0.35" (88.4 x 8.9 x 8.9 mm)

RF Connector: Female V Connector

Operating Wavelength: 1.55 microns (C-Band and L-Band) (0.8, 1.06, 1.3 microns available)

Input Fiber: Polarization Maintaining

Output Fiber: Single Mode or Polarization Maintaining

Optical Connections: FC/UPC Standard (FC/APC & Others Available)

Options: Ultra Low-Loss, Dual Wavelength Operation (1.3/1.55)

Options: Integrated Monitor Photodiode, Integrated Polarizer

Options: External RF Termination Port, Integrated Phase Modulator

Options: Dual Complementary Output (1x2, 2x2)

Options: Custom Alpha Chirp Factors
